Description
Netgate 8200 MAX – Enterprise pfSense® Plus Firewall with 10GbE Connectivity
The Netgate 8200 MAX is a high-performance firewall appliance built for organisations that demand enterprise-class security, multi-gigabit networking, and reliable VPN connectivity. Powered by pfSense® Plus software, it delivers advanced firewall protection, intelligent routing, intrusion detection and prevention (IDS/IPS), secure remote access, and comprehensive traffic management in a compact and efficient platform.
Designed to handle demanding workloads, the Netgate 8200 MAX features an Intel Atom C3758R with QAT, 8-core @ 2.4 GHz processor, 16GB DDR4 ECC memory, and a fast 128 GB NVMe M.2 SSD. This powerful hardware combination provides the performance required for high-throughput routing, encrypted VPN tunnels, deep packet inspection, and complex firewall policies, making it an ideal solution for businesses, data centres, educational institutions, and managed service providers (MSPs).
The appliance offers flexible, high-speed connectivity with 2 × 10GbE SFP+ WAN ports, 4 × 2.5GbE RJ45 Ethernet (LAN) ports, and 2 x Auto media detect 1 Gbps (RJ45 copper / SFP fiber) combo WAN ports, enabling organisations to build scalable, future-ready network infrastructures. Whether you're deploying fibre connectivity, segmenting networks with VLANs, or supporting bandwidth-intensive applications, the Netgate 8200 MAX delivers the speed and flexibility required for modern enterprise environments.
HARDWARE SPECIFICATION:
|
CPU |
Intel Atom C3758R with QAT, 8-core @ 2.4 GHz (Denverton family) |
|
Physical Network I/O ports |
(2) 10 Gbps SFP+ WAN ports |
|
Storage |
128 GB NVMe M.2 SSD (B+M Key) |
|
Memory |
16 GB DDR4 w/o ECC, single channel (soldered down) |
|
Physical Expansion Card Slots |
|
|
1x Mini-PCIe Slot 2x m.2 (Key-B slot) for NVMe (PCIe, USB2.0, USB3.0) |
|
|
Console Port |
1x auto-detect combo port with "Cisco pinout" RJ45 or Micro-B |
|
USB Ports |
2x USB 3.0 jacks (USB-A female) Located on right side rear / lead out to right side front panel of 1U rack |
|
LED |
3x 4-color LEDs (RGB + amber) Software / bootloader controllable via Microchip MCU |
|
Enclosure |
1U Rack - Aluminum, plastic, and steel enclosure. 19 x 10 x 1.75 inches |
|
Cooling |
Active - integrated quiet chassis fan with onboard control |
|
Power |
External ITE P/S AC/DC 100-240V, 50-60 Hz, 12V 5.0A (60W), threaded (locking) barrel connector. - AC Inlet: IEC320-C7 (2 PIN) - Power Cord: One US, UK, EU or ANZ power cord included - UK Power Cord: BS 1363 to IEC320-C7 |
|
Environmental |
0°C (32°F) to 40°C (104°F) - ambient |
Product Notes:
- Ships with the latest version of pfSense Plus software
- Not PoE Compatible
- Ships with UK cord. Easily changed by purchasing compatible AC power cord with IEC320-C7 (2 PIN) plug.
- Ships with 3 foot USB Micro-B to USB-A console cable.
- Netgate 8200 systems are actively cooled. Take care to avoid any obstructions to the chassis and lid venting.
- Netgate 8200 systems may be rack mounted with other devices directly above or below the Netgate system. Heat sources placed immediately below or in direct contact with the underside (chassis) of the 8200 system should measure less than 40°C / 104°F surface temperature.
Your purchase includes all of these super neat things, which will help you get started with pfSense Plus software:
- Complimentary TAC Lite 24x7 zero-to-ping support from Netgate Global Support
- Access to the continuously updated pfSense online documentation
- ACB: Automatic Encrypted Configuration Backup Service
Warranty And Support Information
- Technical assistance is available from Netgate Global Support 24x7x365.
- TAC Lite is included with the purchase of your Netgate appliance.
-
TAC Professional and TAC Enterprise support plans are also available.
- Help is available on our community forum here.
- One-year manufacturer's hardware warranty.
- Standard 30-day return policy. Telappliant does not sell returned or second-hand products. An open-box fee may apply.
-
All specifications subject to change without notice.
